AST3485SI Type RS-485/422 Bus Transceiver Circuit
AST3485SI Type RS-485/422 Bus Transceiver Circuit
Features
-
Operating voltage: 3.3V±0.3V
Input high level voltage: ≥2.0V
Input low level voltage: ≤0.8V
Output high level voltage: ≥VCC-0.4V
Output low level voltage: ≤0.4V
Driver differential output delay: 35ns
Driver differential output conversion time: ≤25ns
Receiver transmission delay: ≤90ns
Receiver transmission delay swing rate: ≤10ns
Data transfer rate: 10Mbps
ESD: 8KV at bus end, 2KV at digital end
Package: Plastic SOP8
Partial parameters
-
Operating temperature range: -40 ℃ ~ 85 ℃
Storage temperature range: -65 ℃ ~ 150 ℃
