AST3096ES Type RS-485/422 Bus Receiver Circuit
AST3096ES Type RS-485/422 Bus Receiver Circuit
Features
-
Package: SOP16
Quality level meets GJB7400 N1 level
Partial parameters
-
Operating voltage: 3.3V ±10%V
Input threshold voltage: ±0.3V
Output high level voltage: ≥VCC-0.4V
Output low level voltage: ≤0.4V
Data transmission delay (typical): 123ns
Maximum data transfer rate: 10Mbps
ESD (HBM mode): bus side ±8KV, other IO ports ±2KV
Storage temperature range：-65℃～150℃
Maximum junction temperature: 150℃
