QSLM0004B-C4 Limiter Chip

首页 > Products > RF Devices >

QSLM0004B-C4 Limiter Chip


Features





    Frequency range: 0.5-4GHz
    Insertion Loss: 0.35dB (Tpy.)
    Limiting level: 13dBm
    Power Withstanding: 45dBm (CW)
    50Ohm Input/Output
    Chip size: QFN 4X4





Partial parameters





    Operating temperature -55 to +125°C
    Storage temperature -65～+150°C

  •
