QSPS009013-6B-PD-PQ6 6-bit Digital Phase Shifter Chip

首页 > Products > RF Devices >

QSPS009013-6B-PD-PQ6 6-bit Digital Phase Shifter Chip


Features





    Frequency range: 0.9-1.3GHz
    Insertion Loss: 4.8dB (Typ.)
    Insertion Loss Fluctuation: 1.0dB
    Phase shift accuracy (RMS): 1.2o Integrated control logic
    Supply Voltage: -5V
    50Ohm Input/Output
    100% on-chip testing
    Chip size: QFN 6X6




Partial parameters





    Operating temperature -55 to +85°C
    Storage temperature -65～+150°C
