ASTK704 Low Voltage High-Speed 4-to-1 Multiplexer
ASTK704 Low Voltage High-Speed 4-to-1 Multiplexer
Features
-
Power supply range: single supply 2.5V~5.5V
Four-select multiplexer: 4:1×1
Low on-resistance: 2.5 Ω
Power consumption: 0.01 uW
-3dB bandwidth: 100 MHz
Fast switching time: Ton=20 ns
Toff=10 ns
TTL/CMOS level compatible
Rail-to-rail operation
Package: Plastic MSOP-10
Applications
-
Communication system
Video channel switching
Sample hold system
Battery powered systems
Data sampling system
Audio signal routing system
Partial parameters
-
Operating Ambient Temperature: -40℃～125℃
Maximum junction temperature: 150℃
