Features




3.3 V supply (2.7 V to 3.6 V)
Fully compatible with AD9245
SNR = 71 dBc
SFDR = 83.0 dBc
Low-power design: 210 mW at 80 MSPS
AD9245: 366 mW at 80 MSPS
Differential input 500 MHz bandwidth
Integrated on-chip voltage reference and sample-and-hold circuitry
DNL = ±0.3 LSB
Flexible analogue input range: 1 Vp-p to 2 Vp-p range
Offset binary or binary complement data format
On-chip integrated clock duty cycle stabilisation circuitry

Applications



Medical imaging equipment
Communication transceivers
Battery powered devices
Handheld oscilloscope spectrum analyser
•




Partial parameters




Storage temperature: -65～150℃
Operating temperature: -55～125℃
Maximum junction temperature: 150℃
