Features




16-bit, 200kSPS (all channels)
Input buffer with 1MΩ analogue input impedance
Operating temperature range: -40°C to +125°C
5V single analogue power supply
VDRIVE supply voltage: 2.3V to 5V
±30V input clamping protection, 8kV ESD
2nd order anti-alias analogue filter
On-chip precision reference source and reference voltage source buffer
True bipolar analogue input range: ±10V, ±5V
Integrated digital filter oversampling
SNR 86dB (no oversampling) 95dB (64x oversampling)
QFP-64 Package 12mm x 12mm

Applications



Power line monitoring
Relay protection
Multi-phase motor control
Instrumentation and control systems
Data acquisition systems

Partial parameters




Operating temperature range: -40°C to 85°C
Storage temperature range: -65°C to 150°C
Maximum junction temperature: 150°C
