Features





24-bit, no missing codes
Fixed channel or auto channel scanning
Fixed channel data rate:125kSPS
Auto scan data rate:23.7kSPS/channel
Single conversion
16 single-ended or 8 differential inputs
Unipolar (+5V) operation
Low noise: 2.8 μVRMS at 1.8kSPS
0.001% integral non-linearity
DC stability (typical).
0.02 μV/°C offset drift, 0.4 ppm/°C gain drift
Open-Sensor Detection
Conversion control
Multiple outputs for external signal conditioning
On-chip temperature, reference, offset, gain and supply voltage readback
42mW power consumption
Standby, sleep and shutdown modes
8 General Purpose Inputs and Outputs (GPIOs)
32.768kHz crystal oscillator or external clock
Fully compatible with TI's ADS1258
QFN-48 package 7mm x 7mm

•




Applications



Medical, avionics, and process control
Machine and system monitoring
Fast scanning multi-channel instruments
Industrial systems
Test and measurement systems
•


Partial parameters




Operating temperature range: -45°C ~125°C
Storage temperature range: -60°C ～150°C
Maximum junction temperature: 150°C
