Features




Output voltage range: 2.5 V to 6.5 V
Multiple output voltage versions available:
- Fixed output voltage range: 1.0v, 1.2v, 1.5v, 1.8v, 2.0v, 2.5v, 2.8v, 3.0v, 3.3v, 4.0v, 4.5v, 5.0v, 5.5v
- Adjustable output voltage range: 1.0 V to 6.0 V
Ultra-high power supply rejection ratio PSRR: 1.0V to 6.0V at 150mA load current
- 70dB/60dB/53dB/45dB at 1K/10K/100K/1MHz at 150mA load current respectively
Excellent load response and linearity response
Ultra-low dropout: only 180mV at 150 mA load current
Low noise: 50 μVRMS typical (100 Hz to 100 kHz)
Fast start-up: 95% of output voltage can be reached at 220us after EN pull-up (1uF Cout, 10nF Cnr)

Applications



WiFi, Wireless LAN, Bluetooth and other RF applications Various types of LCD monitors and LCD TVs
MP3/MP4 media players
DVD decoders and TV set-top boxes
Smart phones, PDAs, tablets and other handheld devices digital cameras and camcorders sensor power supply
•


Partial parameters




Operating Temperature Range: -40℃～125
Storage Temperature Range: -50℃～150℃
Maximum Junction Temperature: 150℃
