Features




Core
Memory
LCD parallel interface, 8080/6800 mode compatible
Clock, reset and power management
Low power consumption
Three 12-bit, 2.4 MSPS ADCs: up to 24 channels, up to 7.2 MSPS in triple-crossover mode
Two 12-bit D/A converters
Universal DMA: 16-channel DMA controller with FIFO and burst support
Up to 17 timers: 12 16-bit timers, and 2 32-bit timers up to 168 MHz, each with
4 input capture/output compare/PWM, or pulse counter with quadrature (incremental) encoder inputs
Debug Mode
Up to 140 I/O ports with interrupt function
Up to 15 communication interfaces
Advanced Connection Functions
8~14 bit parallel camera interface: up to 54MB/s speed
True random number generator
CRC calculation unit
RTC: sub-second accuracy, hardware calendar
96-bit unique ID



Applications



Motor drives and application control
Medical equipment
Industrial applications: PLCs, inverters, circuit breakers
Printers, scanners
Alarm systems, video phones, HVAC
Home audio equipment

Partial parameters




Maximum junction temperature: 125°C
Operating ambient temperature range: -40°C to 105°C
